JPK Nanowizard 3 Bioscience AFM

Responsible: Adrian Iovan, Anders Liljeborg



AFM equipped with inverted optical microscope with EPI-fluorescence illumination.



Short manual     Work flow (condensed)

Documents

System brochure (pdf)    Handbook (pdf)    User Manual (pdf)    Data Processing Software Manual (pdf)

Camera installation and settings (pdf)

Fluorescence filters

Filter cubes currently available in optical inverted microscope:
LabelFluorophoreExcitation [nm]Emission [nm]
(UV)DAPI377447
(B)GFP472520
(G)Cy3531593
