- Horisontal and vertical resolution better than one nm.
- Accomodate sample sizes up to six inches.
- Scanning modes: contact, tapping, IMAFM.
Repsonsible: Anders Liljeborg, Erik Tholén
User Manual, step-by-step.
Nanoscope Training Notebook v.3.0 (pdf) (Veeco y. 2000)
Testing the tool with 10 µm grid.
Using MFM on disk platter and tape sample.
|
|
| Antivibration and soundproofing hood mounted on air dampened table | Close up of scan head, video camera and sample stage. |
|
|
| Close up of scan head and video camera. Green arrows indicate lock screw for scan head and adjustment for laser beam. | Controller and power supply containing vacuum pump for stage and securing samples. |
Testing the tool with 10 µm grid.
